Devices and Connectivity:

The devices chosen for the system included coffee-makers, kettles, air fryers, switches, dimmers, the temperature and humidity thermostat, curtain motors, door locks, motion sensors, and water leaks sensor, all compatible with the Tuya system. Before the integration, the abilities of each device had to be checked instead of taking for granted that all the Tuya devices included the same features.

Home appliances connected to the home router through Wi-Fi. Zigbee devices and sensors connected through Tuya devices compatible with Zigbee, while devices and systems which supported Bluetooth communicated using Bluetooth.

Integration of Applications and Devices:

Integration of Smart Life App SDK in native applications for iOS and Android platforms has been done to provide users account management, organize home or room, add new devices and share them.

Every device has its device ID, product ID, room and function schema, which allows us to map Tuya data points onto interface components, that is: working with values that are either Boolean in case of switching commands; numeric for temperature and illuminance; and enumerated types for appliance modes.

Kitchen appliance panels support only commands that are possible to execute, that is: mode of operation, temperature, timer and status. Manufacturer safety devices are authoritative in the system state – a simple smart plug will not trigger events in the native appliances.

For hardware integration, custom integration path was chosen for hardware. Tuya communication module and micro control unit (MCU) SDK were used. In this case MCU would process instructions and send back Tuya data points through the serial interface with the help of protocols and data dictionaries.

HVAC, Locks, and Automation:

Compatible thermostats exposed setpoint, operating mode, and reported temperature. Existing air conditioners could use compatible infrared controllers, but transmitted commands were distinguished from independently verified equipment status.

Lock integration used the relevant Smart Lock SDK capabilities for supported credentials, temporary passwords, access records, and alerts. Remote unlocking depended on the specific lock solution.

We implemented occupancy-based lighting, scheduled curtain operation, temperature-triggered climate control, and leak notifications. Eligible rules involving devices under the same gateway used local linkage; cloud-dependent scenes required internet connectivity.

Backend, Validation, and Delivery:

Our backend integrated authorized Tuya Cloud APIs and message services for dashboards, event processing, and reporting. Cloud credentials remained server-side, while household permissions governed application access.

SDK callbacks and device reports updated the interface, separating pending commands from confirmed states.

Testing covered pairing, permissions, gateway restarts, connection loss, duplicate events, device resets, and supported firmware updates. The resulting architecture unified household controls while documenting compatibility limits, cloud dependencies, and maintenance requirements for future expansion.

Hardware and System Architecture:

Wi-Fi devices were connected to the hotel network. Zigbee devices communicated through Tuya's gateways. The choice of hardware for the provided locks as well as the connectivity capabilities depended on the selected model of the locks and gateways used.

The architecture consisted of three layers consisting of room devices, the Tuya platform and our own developed applications. The architecture included Smart Life App SDK integration with iOS and Android applications. The administration dashboard exchanged data using our backend systems and managed access via the Tuya Cloud API.

Integration of Devices and Mapping of Rooms:

Our onboarding process involved pairing each device with its corresponding hotel, floor, and room. Our backend server was responsible for ensuring the links between the internal room number, Tuya device number, product number, and category of the device.

In detail, we checked the information schema of all devices. For instance, Boolean data points corresponded to switching operations; numeric data points captured information concerning adjustable parameters like temperature or lighting; categorized data points represented the several operating modes.

This actual functionality has been used to develop the interface. For example, dimmers provided special controls for brightness, while simple relays controlled the switch function only. The curtains were controlled by considering the movement and position functions of the connected device.

Commands, Events, and Automation:

Mobile controls used the SDK's supported device commands. Staff dashboard actions passed through backend authorization checks before calling the relevant cloud API.

Device updates were processed through SDK callbacks and the applicable cloud message service. We maintained reported status separately from requested actions, preventing an accepted command from appearing as a confirmed physical change.

Occupancy events supported lighting and HVAC automation. Door/window contacts supplied additional conditions, such as adjusting climate operation when a window remained open. Delays prevented brief sensor changes from repeatedly switching equipment.

Operational Monitoring and Access Control:

Guest access was limited only to the designated room and authorized tasks without any other permission levels. Employee access was differentiated in accordance with the roles of the employees at workstations' of the reception, housekeeping, maintenance, and administration.

Smart lock procedures had only access rights, time access, and the ability for remote operations depending on the type of device. Electric readings were considered as part of the room accounts for reporting on consumption and conducting investigations if needed.

Validation and Handover:

Testing encompassed failures of pairing, permission denial, gateway outages, delayed status, duplication of events, reassignment of rooms, and resetting equipment.

We documented the hardware available, mapping of data points, dependencies on cloud, and procedures for recovery. The system provided a technological basis for controlling teams, monitoring hotel, and expanding by adding compatible devices to the property.
